Specifications - Samsung Galaxy Xcover 5
Physical specifications
Dimensions
147.1 x 71.6 x 9.2 mm
Weight
172 g
IP rating (protection against dust and water)
IP68 Dust and water resistant (up to 1.5 m for 30 minutes)
Screen and keys
Screen type
PLS IPS touch screen, 16 million colours
Screen size
5.3 inches
Resolution
720 x 1480 pixels
Physical keypad
No
Picture, video and sound
Main camera
16 MP, f/1.8
Front camera
5 MP, f/2.2
Video recorder
1080p@30fps
Flash
Yes
Music player
Yes
FM radio
No
Speaker
Mono
SIM
SIM type
Dual Nano SIM
Processor
Chipset
Exynos 850 (8nm)
CPU
Octa-core (4x2.0 GHz Cortex-A55 & 4x2.0 GHz Cortex-A55)
GPU
Mali-G52
Memory
Storage
64 GB
RAM
4 GB
Memory card slot
Up to 1 TB
Ports
3.5 mm jack
Yes
USB
2.0, USB-C
Network
2G network
Yes
3G network
Yes
4G network
Yes
5G network
No
Connectivity
Bluetooth
5.0, A2DP, LE
Wi-Fi
802.11 a/b/g/n/ac, dual-band
NFC
Yes
GPS
Yes
Sensors
Accelerometer
Yes
Gyroscope
Yes
Compass
Yes
Barometer
No
Battery
Battery type
Non-removable Li-Ion 3000 mAh battery
Operating system
Operating system
Android 11.0
Communication
VoLTE – 4G voice
Yes
VoWi-Fi - Wi-Fi calling
Yes
Tethering
USB
Yes
Wi-Fi hotspot
Yes
Security
Fingerprint sensor
No
Face recognition
2D face recognition
Iris scanner
No
